Electric Lifting Columns EL Series
EL620AZMK
Electric Lifting Columns
| Product Classification | Product Name | CIF: List Price | FOB: List Price | Shipping Date |
|---|---|---|---|---|
| Electric Lifting Columns | EL620AZMK | MYR 25,866 | MYR 21,722 | 29 Working Days |
Included
- Electric Lifting Columns: None
Specifications
Characteristics
Dimensions
Data Download
Other Specifications
Motor General Specifications
| Operating Environment (when operation) | Ambient Temperature | 0∼+40°C (Non-freezing)∗ |
|---|---|---|
| Ambient Humidity | 85% max. (Non-condensing) | |
| Atmosphere | No corrosive gases or dust. No exposure to water, oil or other liquids. | |
| Multi-Rotation Detection Range in Power OFF State | ±900 rotations (1800 rotations) | |
- ∗
- According to Oriental Motor’s measurement conditions
Electromagnetic Brake Specifications
| Type | Power off activated type |
|---|---|
| Power Supply Voltage | 24 V DC±5%∗ |
| Power Supply Current [A] | 0.25 |
| Time Rating | Continuous |
- ∗ The specification for the cable type products with an electromagnetic brake is 24 VDC±4 % when extending to 20 m using the connection cable.
Travel Direction
The factory default setting for the table travel direction is as follows.
