Hollow Rotary Actuator DGII Series Product Code

AZ Series Equipped

AC Input

Hollow Rotary Actuator Motor Vertical Mounting

  • DGM 1
  • 130 2
  • R 3
  • -
  • AZ 4
  • A 5
  • C 6
  • R 7
1 Actuator Product Line
DGM
DGII Series actuator motor vertical mounting
2 Frame Size
85
85 mm
130
130 mm
200
200 mm
3 Type of Output Table Supporting Bearing
R
Cross-roller bearing
4 Equipped Motor
AZ
AZ Series
5 Motor Type
A
Standard
M
With electromagnetic brake
6 Motor Type
C
AC input specification
7 Cable Outlet Direction*
Blank
Down side
R
Right side
L
Left side
  • *The cable outlet direction is the direction of the cable when the output table is facing you and the motor is positioned underneath.
Cable Outlet Direction

Hollow Rotary Actuator Motor Horizontal Mounting

  • DGB 1
  • 85 2
  • R 3
  • 12 4
  • -
  • AZ 5
  • A 6
  • C 7
  • R 8
1 Actuator Product Line
DGB
DGII Series actuator motor horizontal mounting
2 Frame Size
85
85 mm
130
130 mm
3 Type of Output Table Supporting Bearing
R
Cross-Roller Bearing
4 Gear Ratio
5 Equipped Motor
AZ
AZ Series
6 Motor Type
A
Standard
M
With electromagnetic brake
7 Motor Type
C
AC input specification
8 Cable Outlet Direction*
R
Right side
L
Left side
  • *The cable outlet direction is the direction of the cable when the output table is positioned above and the motor is facing you.
Cable Outlet Direction

Driver

  • AZD 1
  • -
  • C 2
  • D 3
1 Driver Type
AZD
AZ Series driver
2 Power Supply Input
A
Single-Phase 100-120 VAC
C
Single-Phase/Three-Phase 200-240 VAC
3 Product Line
D
Built-in controller type
X
Pulse input type with RS-485 communication
Blank
Pulse input type
EP
EtherNet/IP compatible
ED
EtherCAT compatible
PN
PROFINET compatible

Connection Cable Sets/Flexible Connection Cable Sets

  • CC 1
  • 050 2
  • V 3
  • Z 4
  • F 5
  • B 6
1
CC
Cable
2 Length
005
0.5 m
010
1 m
015
1.5 m
020
2 m
025
2.5 m
030
3 m
040
4 m
050
5 m
070
7 m
100
10 m
150
15 m
200
20 m
3 Reference Number
4 Applicable Model
Z
For AZ Series
5 Cable Type
F
Connection cable set
R
Flexible connection cable set
6 Description
Blank
For type without electromagnetic brake
B
For electromagnetic brake type

DC Input

Hollow Rotary Actuator Motor Vertical Mounting

  • DGM 1
  • 130 2
  • R 3
  • -
  • AZ 4
  • A 5
  • K 6
  • R 7
1 Actuator Product Line
DGM
DGII Series actuator motor vertical mounting
2 Frame Size
60
60 mm
85
85 mm
130
130 mm
3 Type of Output Table Supporting Bearing
R
Cross-Roller Bearing
Blank
Deep-groove ball bearing
4 Equipped Motor
AZ
AZ Series
5 Motor Type
A
Standard
M
With electromagnetic brake
6 Motor Type
K
DC input specification
7 Cable Outlet Direction*
Blank
Down side
R
Right side
L
Left side
  • *The cable outlet direction is the direction of the cable when the output table is facing you and the motor is positioned underneath.
Cable Outlet Direction

Hollow Rotary Actuator Motor Horizontal Mounting

  • DGB 1
  • 85 2
  • R 3
  • 12 4
  • -
  • AZ 5
  • A 6
  • K 7
  • R 8
1 Actuator Product Line
DGB
DGII Series actuator motor horizontal mounting
2 Frame Size
85
85 mm
130
130 mm
3 Type of Output Table Supporting Bearing
R
Cross-Roller Bearing
4 Gear Ratio
5 Equipped Motor
AZ
AZ Series
6 Motor Type
A
Standard
7 Motor Type
K
DC input specification
8 Cable Outlet Direction*
R
Right side
L
Left side
  • *The cable outlet direction is the direction of the cable when the output table is positioned above and the motor is facing you.
Cable Outlet Direction

Driver

  • AZD 1
  • -
  • K 2
  • D 3
1 Driver Type
AZD
AZ Series driver
2 Power Supply Input
K
24 VDC/48 VDC
3 Product Line
D
Built-in controller type
X
Pulse input type with RS-485 communication
Blank
Pulse input type
EP
EtherNet/IP compatible
ED
EtherCAT compatible
PN
PROFINET compatible

Connection Cable Sets/Flexible Connection Cable Sets

  • CC 1
  • 050 2
  • V 3
  • Z 4
  •   5
  • F 6
  • B 7
  • 2 8
1
CC
Cable
2 Length
005
0.5 m
010
1 m
015
1.5 m
020
2 m
025
2.5 m
030
3 m
040
4 m
050
5 m
070
7 m
100
10 m
150
15 m
200
20 m
3 Reference Number
4 Applicable Model
Z
For AZ Series
5 Reference Number
Blank
For DGM85 and DGM130
2
For DGM60
6 Cable Type
F
Connection Cable Set
R
Flexible Connection Cable Set
7 Description
Blank
For type without electromagnetic brake
B
For electromagnetic brake type
8 Cable Specification
2
For DC input

AZX Series Equipped

Hollow Rotary Actuator

  • DGM 1
  • 200 2
  • R 3
  • 18 4
  • -
  • AZX 5
  • A 6
  • C 7
1 Series Name
DGM
DGII Series
2 Frame Size
200
200 mm
3 Type of Output Table Supporting Bearing
R
Cross-Roller Bearing
4 Gear Ratio
5 Equipped Motor
AZX
AZX Series
6 Motor Type
A
Standard
M
With electromagnetic brake
7 Motor Type
C
AC input specification

Driver

  • AZXD 1
  • -
  • S 2
  • EP 3
1 Driver Type
AZXD
AZX Series driver
2 Power Supply Input
S
Single-Phase/Three-Phase 200-240 VAC
3 Product Line
ED
EtherCAT compatible
EP
EtherNet/IP compatible
PN
PROFINET compatible

Connection Cable Sets/Flexible Connection Cable Sets

  • CC 1
  • 010 2
  • V 3
  • X 4
  • F 5
  • B 6
1
CC
Cable
2 Length
010
1 m
020
2 m
030
3 m
050
5 m
070
7 m
100
10 m
150
15 m
200
20 m
3 Reference Number
4 Applicable Model
X
For AZX Series
5 Cable Type
F
Connection Cable Set
R
Flexible Connection Cable Set
6 Description
Blank
For type without electromagnetic brake
B
For electromagnetic brake type
